Outdoor Full Color LED Display P5 LED Display Screen Module

FOB Reference Price:Get Latest Price
$18.00 - $50.00 / Pieces | 5 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanxi, China (Mainland)
Brand Name:
GKGD
Model Number:
P5
Usage:
Outdoor, outdoor
Tube Chip Color:
Full Color
Display Function:
Video, live broadcasting, video
Pixels:
5 mm, 5mm
Screen Dimension:
Customized
Module size:
320*160mm
Pixel density:
40,000 dots/sqm
Brightness:
6000cd/sqm
Model Name:
Outdoor P5 LED display module
Certificate:
CE ROHS FCC
Power Supply:
Chuanglian
Warranty:
2 years
Supply Ability
Supply Ability:
300000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
40pcs/Carton
Size: 400*305*390mm
weight: 11.03kgs
Port
SHENZHEN
Lead Time :
Shipped in 3-7 days after payment

Outdoor Full Color LED Display P5 Small Pitch LED Display Screen

Product Description

Features:

1. High brightness, high performance;

2. Extra perfect viewing and vivid images;

3. Most competitive price;

4. Good after-sale.

Module Parameter:

Pixel pitch5mm
Pixel Density40,000 dots/m²
Pixel configuration1R1G1B
LED type3-in-1 SMD2727
Module size160*160mm
Module weight260g
Module resolution32*16dots
Module quantity39.06 pcs/m²
Min. Viewing Distance ≥5m
Brightness≥6000 cd/m²
Viewing AngleH≤120°  V≤120°
Driving Mode1/8 scan constant current driving
InterfaceHUB75
Input voltage4.8-5.5VDC
Max. Power Consumption1000 w/m²
Avg. Power Consumption450 w/m²
Max. Current3.6-4.0A
Frame rate60 frames/s
Refresh Rate≥600Hz
Defective Dots Rate<0.0001 (LED display line standard: ≤ 0.0003)
Decay Rate≤5%/year

Brightness Conformity

>95%
MTBF≥10000 hours
Lifespan≥50000 hours
Protective function

Over-heat/Over-load /Power-down /Power-leakage/Lightning-protection etc.

Operating Temperature -20℃~+50℃
Operating Humidity10-85% no condensation
Storage Temperature-30℃~+60℃
Storage Humidity10-95% no condensation
Control System Parameter
Color temperatureAdjustable by software
Brightness control256 levels, automatic adjustment.
Control wayComputer, real-time, off-line, wireless, network etc.
Communication DistanceCat5 UTP 100 meters, max. 130 meters; or optical fiber.
Product Cases







Packaging & Shipping


Certifications





Company Information



GKGD is a leading manufacturer for various kinds of LED Displays. Certificated qualification and extreme standard let us keep very competitive in the current market. I'm pleased to inform you that we have been working with many companies in Europe, North America, Southeast Asia, etc.

Advantages of Factory:

1. 53000 square meters manufacturing base and more than 3500 employees;
2. Standardized management and production;
3. Complete and integrated LED supply-chain;

4. Own lots of core patents. Till now, 152 patents have been registered and still 74 in applying;

5. Emphasize "Enterprise-University-Academy" cooperation.

6. There are lots of R&D projects undertaking between the Group and the Chinese Academy of Sciences as well as universities in Taiwan and Shanxi;

Our main products:

Indoor full color SMD: P1.25, P1.56, P1.667, P1.875, P1.923, P2, P2.5, P3, P3.33, P3.91, P4, P5

Outdoor full color SMD: P4, P5, P5.93, P6.67, P8, P10

Single/Dual color SMD series: P4.75 (RG/R)-I, P10 (R/W)-I

Rental series SMD: PM3.91-I, PM3.91-O, PM4.91-O

All above products are certified by CE, FCC, RoHS, CCC, CB, ......
